| Varenummer | AM-800480R2TMQW-U0H |
| Mærke | AMPIRE |
| Størrelse | 7.0 |
| Ansøgning | Industrial |
| Løsning | 800×480 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 250:1 |
| Farver | 65K |
| Baggrundsbelysning | WLED |
| Interface | UART |
| fabrikant | AMPIRE |
| modelnavn | AM-800480R2TMQW-U0H |
| skærmstørrelse | 7.0 inch |
| skærmtype | LCM , a-Si TFT-LCD |
| pixel antal | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 152.4 × 91.44 (H×V) |
| omrids (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| rammeareal (mm) | 155.3 × 94.3 (H×V) |
| behandling | - |
| luminans | 400 cd/m² (Typ.) |
| kontrastforhold | 250 : 1 (Typ.) (TM) |
| synsvinkel | 70/70/60/60 (Typ.)(CR≥10) |
| respons | 50 (Typ.)(Tr+Td) ms |
| god udsigt kl | - |
| arbejdstilstand | TN, Normally White, Transmissive |
| farvedybde | 65K 48% NTSC |
| baggrundsbelysning | WLED , With LED Driver |
| masse | - |
| anvendes til | Industrial |
| opdateringshastighed | - |
| berøringsskærm | Without |
| signaltype | UART , 8 pins Connector |
| spændingsforsyning | 4.6/26.0V (Min./Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
