| Varenummer | BT055FWM-N00 |
| Mærke | BOE |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 480×854 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BT055FWM-N00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 480(RGB)×854 , FWVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 68.04×121.05 mm |
| omrids | 72.34×130.86×2.3 mm |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 25 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
