| Varenummer | ACX565AKM-7 |
| Mærke | SONY |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 275 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | CDP |
| panel mærke | SONY |
| panel model | ACX565AKM-7 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | VSPEC II, Normally Black, Transflective |
| aktivt område | 76.8×46.08 mm |
| omrids | 87.9×52.18 mm |
| overflade | |
| lysstyrke | 275 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 12/7 (Typ.)(Tr/Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 3S2PWLEDWithout Driver |
| signal interface | CDP (2 Lane) + SPI, 24 pins |
| indgangsspænding | 1.8/2.75V (Typ.)(VDDI/VDD) |
| Ansøgning | MPH |
