| Varenummer | H027QT01 |
| Mærke | AUO |
| Størrelse | 2.7 |
| Ansøgning | MPH |
| Løsning | 208×320 |
| Sammensætning | LCM |
| Lysstyrke | 60 |
| CR | 50:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AU Optronics |
| panel model | H027QT01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.7 inch |
| løsning | 208(RGB)×320 |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 36.816×56.64 mm |
| omrids | 45.8×69.17 mm |
| overflade | |
| lysstyrke | 60 cd/m² (Typ.) |
| kontrastforhold | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 10/30 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
