| Varenummer | LS040T8LX02 |
| Mærke | SHARP |
| Størrelse | 4.0 |
| Ansøgning | MPH |
| Løsning | 480×854 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI |
| panel mærke | SHARP |
| panel model | LS040T8LX02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×854 , FWVGA |
| visningstilstand | Normally Black, Transflective |
| aktivt område | 50.04×89.03 mm |
| omrids | 54.84×98.03×1.55 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.)(Transmissive)14:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 15 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S6PWLEDWithout Driver |
| signal interface | MDDI (2 data lanes), 26 pins |
| indgangsspænding | 1.8/2.85V (Typ.)(VDD/AVDD) |
| Ansøgning | MPH |
| A040CN01 V2 | AUO | 4.0 | 480×234 |
| AMS395GB01 | Samsung | 4.0 | 360×640 |
| LB040Q02-TD02 | LG Display | 4.0 | 320×240 |
| LB040Q03-TD01 | LG Display | 4.0 | 320×240 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LS040B3SX01 | SHARP | 4.0 | 640×960 |
| LS040T3SW01 | SHARP | 4.0 | 540×960 |
| LS040T8LX02 | SHARP | 4.0 | 480×854 |
| TM040YDZ01 | Tianma | 4.0 | 480×800 |
| AMEJ006 | Samsung | 2.8 | 240×400 |
| AMFN888 | Samsung | 3.1 | 480×800 |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| DLC0320DUG | Other | 3.2 | 240×320 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| LH350WS1-SD01 | LG Display | 3.5 | 640×960 |
| LMS501KF03 | Samsung | 5.0 | 480×800 |
| PJ045IC-01F | Innolux | 4.5 | 720×1280 |
| TM018FDZ02 | Tianma | 1.8 | 128×160 |
