| Varenummer | CT022TN15 |
| Mærke | Innolux |
| Størrelse | 2.2 |
| Ansøgning | MPH |
| Løsning | 176×220 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 300:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | INNOLUX |
| panel model | CT022TN15 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.2 inch |
| løsning | 176(RGB)×220 , QCIF+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 34.848×43.56 mm |
| omrids | 42.3×57.5 mm |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 65K/262K , CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 55/55/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S1PWLEDWithout Driver |
| signal interface | CPU, 20 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/VCI) |
| Ansøgning | MPH |
