| Varenummer | AMS465GS53 |
| Mærke | Samsung |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | Assembly |
| Lysstyrke | 300 |
| CR | 3400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | SAMSUNG |
| panel model | AMS465GS53 |
| paneltype | AM-OLED , Assembly |
| panelstørrelse | 4.7 inch |
| løsning | 720RG(BG)×1280 , WXGA |
| aktivt område | 57.96×103.04 mm |
| omrids | 66.36×131.8 mm |
| overflade | Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 3400 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 44 pins |
| indgangsspænding | 2.2/3.1/3.8V (Typ.)(VDD3/VCI/VBAT) |
| Ansøgning | MPH |
