| Varenummer | H020HD01 V0 |
| Mærke | AUO |
| Størrelse | 2.0 |
| Ansøgning | MPH |
| Løsning | 176×220 |
| Sammensætning | OLED |
| Lysstyrke | 105 |
| CR | 10000:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | self |
| Interface | CPU |
| panel mærke | AUO |
| panel model | H020HD01 V0 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 2.0 inch |
| løsning | 176(RGB)×220 , QCIF+ |
| aktivt område | 31.152×38.94 mm |
| omrids | 39.52×53.2 mm |
| overflade | Hard coating |
| lysstyrke | 105 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Typ.) |
| vise farver | 65K/262K (6-bit), CIE193168% |
| synsvinkel | 30/30/30/30 (Typ.)(CR≥2)(L/R/U/D) |
| driver ic | Built-in uPD161621 + uPD161644 |
| signal interface | CPU, 34 pins |
| indgangsspænding | 3.3/-7.0V (Typ.)(VCC/VSS) |
| Ansøgning | MPH |
