| Varenummer | LQ055T3SX04 |
| Mærke | SHARP |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | SHARP |
| panel model | LQ055T3SX04 |
| paneltype | IGZO TFT-LCD , CELL |
| panelstørrelse | 5.5 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.84×128.16 mm |
| overflade | |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 4.2% (Typ.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | COG Built-in NT35532 |
| Ansøgning | MPH |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| LQ055K3SX02 | SHARP | 5.5 | 720×1280 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX02Z | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LQ055W1GC01 | SHARP | 5.5 | 1024×600 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224BC35-20R | NLT | 5.5 | 320×240 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| H546TAN01.0 | AUO | 5.5 | 720×1280 |
| LH350H01-FD01-A41 | LG Display | 3.5 | 320×480 |
| LH350H02-FD02 | LG Display | 3.5 | 320×480 |
| LS043T1LX01A | SHARP | 4.3 | 540×960 |
| RGS15128128FH035 | RiTdisplay | 1.46 | 128×128 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TM020HBH03 | Tianma | 2.0 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
