| Varenummer | B080UAN01.4 |
| Mærke | AUO |
| Størrelse | 8.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | B080UAN01.4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 107.64×172.224 mm |
| omrids | 114.6×184.6×3.65 mm |
| overflade | Hard coating (1H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S3PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 45 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| B080UAN01.4 | AUO | 8.0 | 1200×1920 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LSL080AL02-B01 | Samsung | 8.0 | 800×1280 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| NDS0708001280-31 | SEBO | 7.0 | 800×1280 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
