| Varenummer | H430VL02 V4 |
| Mærke | AUO |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | H430VL02 V4 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 56.16×93.6 mm |
| omrids | 62.46×105.9 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) |
| Ansøgning | MPH |
| 990000475P | TPO | 4.3 | 800×480 |
| AT043TN13 | Innolux | 4.3 | 480×272 |
| H430VL02 V1 | AUO | 4.3 | 480×800 |
| H430VL02 V4 | AUO | 4.3 | 480×800 |
| HSD043I9W1-A00-R0 | HannStar | 4.3 | 480×272 |
| LH430WV1-SD02 | LG Display | 4.3 | 480×800 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
| P0430WQLC-T | CMEL | 4.3 | 480×272 |
| DLC0300AMG | Other | 3.0 | 240×400 |
| H020HD01 V0 | AUO | 2.0 | 176×220 |
| HVA32WV1-D00 | HYDIS | 3.2 | 480×800 |
| LH300WQ1-ED01 | LG Display | 3.0 | 240×400 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LQ034J1LX01 | SHARP | 3.4 | 320×480 |
| LS024J3LX01 | SHARP | 2.4 | 320×480 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| PJ055IA-14C | Innolux | 5.5 | 1080×1920 |
| TFT-GG1P0553UTSW-W-E | Other | 1.7 | 176×220 |
