| Varenummer | DLC0240LZG-4 |
| Mærke | Other |
| Størrelse | 2.4 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 350:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | DLC |
| panel model | DLC0240LZG-4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 36.72×48.96 mm |
| omrids | 42.72×60.35 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/50/30 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | CPU, 45 pins |
| indgangsspænding | 2.8/3.3V (Typ./Max.) |
| Ansøgning | MPH |
