| Varenummer | TM020GDH42 |
| Mærke | Tianma |
| Størrelse | 2.0 |
| Ansøgning | MPH |
| Løsning | 176×220 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | |
| panel mærke | TIANMA |
| panel model | TM020GDH42 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.0 inch |
| løsning | 176(RGB)×220 , QCIF+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 31.68×39.6 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 65K/262K , CIE193160% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLEDWithout Driver |
| Ansøgning | MPH |
