| Varenummer | TM040YDZ01 |
| Mærke | Tianma |
| Størrelse | 4.0 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | TIANMA |
| panel model | TM040YDZ01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 51.85×86.4 mm |
| omrids | 57.34×97.8×3 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193165% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 50/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S1PWLEDWithout Driver |
| signal interface | MIPI (1 data lane), 25 pins |
| Ansøgning | MPH |
