| Varenummer | LH300WQ1-ED01 |
| Mærke | LG Display |
| Størrelse | 3.0 |
| Ansøgning | MPH |
| Løsning | 240×400 |
| Sammensætning | OLED |
| Lysstyrke | 210 |
| CR | 2000:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | self |
| Interface | CPU/RGB/SPI |
| panel mærke | LG Display |
| panel model | LH300WQ1-ED01 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 3.0 inch |
| løsning | 240(RGB)×400 , WQVGA |
| aktivt område | 38.88×64.8 mm |
| omrids | 44×74.6 mm |
| overflade | Hard coating |
| lysstyrke | 210 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | 65K/262K , CIE193185% |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 40 pins |
| indgangsspænding | 2.8/2.8/3.7V (Typ.)(VDD/VCC/VBATT) |
| Ansøgning | MPH |
