| Varenummer | LS055R1SC01 |
| Mærke | SHARP |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1440×2560 |
| Sammensætning | LCM |
| Lysstyrke | 480 |
| CR | 1300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS055R1SC01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 1440(RGB)×2560 , Quad-HD |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.87×128.45×1.45 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 480 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 45 pins |
| indgangsspænding | 1.8/5.75/-5.75V (Typ.)(IOVDD/AVDD+/AVDD-) |
| Ansøgning | MPH |
