| Varenummer | COM40T4M46ULX |
| Mærke | ORTUSTECH |
| Størrelse | 4.0 |
| Ansøgning | HHP |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | ORTUSTECH |
| panel model | COM40T4M46ULX |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | Buenaview, Normally Black, Transmissive |
| aktivt område | 51.84×86.4 mm |
| omrids | 57.2×97.9 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Min.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 18/17 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S7PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | HHP |
