| Varenummer | CT035TN02 |
| Mærke | Innolux |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 320×480 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 500:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | CHIMEI INNOLUX |
| panel model | CT035TN02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×480 , HVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 48.96×73.44 mm |
| omrids | 54.76×85.24×2.1 mm |
| overflade | |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 65K/262K , CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S5PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 50 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(VDD3/VCI) |
| Ansøgning | MPH |
