| Varenummer | LB035Q04-TD08 |
| Mærke | LG Display |
| Størrelse | 3.5 |
| Ansøgning | PND |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 370 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Parallel/Serial |
| panel mærke | LG Display |
| panel model | LB035Q04-TD08 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.9×63.9×3.35 mm |
| overflade | Clear, Hard coating (3H) |
| lysstyrke | 370 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLED |
| signal interface | Digital RGB (8/18/24-bit) + SPI, 60 pins |
| indgangsspænding | 3.3V (Typ.)(VCI) |
| Ansøgning | PND |
