| Varenummer | TD035STED7 |
| Mærke | TPO |
| Størrelse | 3.5 |
| Ansøgning | PDA |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 115 |
| CR | 100:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TPO |
| panel model | TD035STED7 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 53.28×71.04 mm |
| omrids | 64×85×5.5 mm |
| overflade | |
| lysstyrke | 115 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193136% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 60 pins |
| indgangsspænding | 2.8/2.8/5/10/-5.0V (Typ.)(VDD1/VDD2/AVDD/VGH/VVEE) |
| Ansøgning | PDA |
