| Varenummer | PD035OX1 |
| Mærke | E Ink |
| Størrelse | 3.5 |
| Ansøgning | DSC |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Parallel/Serial |
| panel mærke | PVI |
| panel model | PD035OX1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 71.6×52.65 mm |
| omrids | 84.03×65.24×3.73 mm |
| overflade | Antiglare |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S2PWLEDWithout Driver |
| signal interface | Digital RGB (8/24-bit), CCIR601/656, 60 pins |
| indgangsspænding | 3.3/3.3/5.0/15/-15V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| Ansøgning | DSC |
