| Varenummer | YX101GL-01A |
| Mærke | SEBO |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 850 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SEBO |
| panel model | YX101GL-01A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 229.46×149.1×6.9 mm |
| overflade | Antiglare |
| lysstyrke | 850 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| indgangsspænding | 2.5/8.2/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ansøgning | PAD |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| CLAA101WJ03 XG | CPT | 10.1 | 1366×768 |
| HSD101PWW1-B00-C11 | HannStar | 10.1 | 1280×800 |
| LP101WH1-TLA1 | LG Display | 10.1 | 1366×768 |
| LTN101AT03-801 | Samsung | 10.1 | 1366×768 |
| N101BCG-GK1 | Innolux | 10.1 | 1366×768 |
| PJ101IA-01A | Innolux | 10.1 | 1280×800 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
| YX101GL-01A | SEBO | 10.1 | 1280×800 |
| YX101UWX002C | SEBO | 10.1 | 1280×800 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| BP070WS1-400 | BOE | 7.0 | 1024×600 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| LSL080AL02-B01 | Samsung | 8.0 | 800×1280 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| N070ICE-GB2 | Innolux | 7.0 | 800×1280 |
| P080KDZ-3Z1 | Innolux | 8.0 | 1200×1920 |
| TFT08925601600 | SEBO | 8.9 | 2560×1600 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
