| Varenummer | A043FW03 V2 |
| Mærke | AUO |
| Størrelse | 4.3 |
| Ansøgning | HHP |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A043FW03 V2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | AMVA3, Normally Black, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2×3.1 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 17/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Ansøgning | HHP |
