| Varenummer | BTL507212-W746L |
| Mærke | BOE |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BTL507212-W746L |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 62.1×110.4 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 27 pins |
| indgangsspænding | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
| AMS495QA01 | Samsung | 5.0 | 960×544 |
| AT050TN34 V.1 | Innolux | 5.0 | 480×272 |
| BTL507212-W677L | BOE | 5.0 | 720×1280 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| BTL507212-W749L | BOE | 5.0 | 720×1280 |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| LA050WQ2-SD02 | LG Display | 5.0 | 480×240 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
| AMS300FW01-0 | Samsung | 3.0 | 240×400 |
| CLAF055LA41 TXX | CPT | 5.5 | 540×960 |
| LD043WV1-SP01 | LG Display | 4.3 | 480×854 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LQ055K3SX02 | SHARP | 5.5 | 720×1280 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| LS063K3SX01 | SHARP | 6.3 | 720×1280 |
| LS063R1SX01 | SHARP | 6.3 | 1440×2560 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
| PJ045IC-01F | Innolux | 4.5 | 720×1280 |
