| Varenummer | KCG047QV1AA-A210 |
| Mærke | Kyocera |
| Størrelse | 4.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 160 |
| CR | 30:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Kyocera |
| panel model | KCG047QV1AA-A210 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 95.98×71.98 mm |
| omrids | 122.4×90×11.4 mm |
| overflade | Antiglare |
| lysstyrke | 160 cd/m² (Typ.) |
| kontrastforhold | 30:1 (Typ.) |
| vise farver | Color |
| responstid | 490 (Typ.)(Tr+Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥2)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD) |
| Ansøgning | IA |
