| Varenummer | H381DLN01.0 |
| Mærke | AUO |
| Størrelse | 3.8 |
| Ansøgning | MPH |
| Løsning | 1080×1200 |
| Sammensætning | OLED |
| Lysstyrke | 100 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | H381DLN01.0 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 3.8 inch |
| løsning | 1080(RGB)×1200 |
| aktivt område | 64.8×72 mm |
| omrids | 67.6×78.95×1.24 mm |
| overflade | |
| lysstyrke | 100 cd/m² (Typ.) |
| kontrastforhold | 3000 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥480)(L/R/U/D) |
| driver ic | COG Built-in RM69071 |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 1.8/4.6/5.8/-2.9V (Typ.)(IOVCC/OVDD/AVDD/OVSS) |
| Ansøgning | MPH |
