| Varenummer | H320QN01 V2 |
| Mærke | AUO |
| Størrelse | 3.2 |
| Ansøgning | MPH |
| Løsning | 320×480 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI/MIPI |
| panel mærke | AUO |
| panel model | H320QN01 V2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.2 inch |
| løsning | 320(RGB)×480 , HVGA |
| visningstilstand | AMVA, Normally Black, Transmissive |
| aktivt område | 45.12×67.68 mm |
| omrids | 50.6×78.9×2.18 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193167% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | MDDI/MIPI, 23 pins |
| indgangsspænding | 1.8/2.85V (IOVDD/AVDD) |
| Ansøgning | MPH |
