| Varenummer | TM030LDHT2 |
| Mærke | Tianma |
| Størrelse | 3.0 |
| Ansøgning | HHP |
| Løsning | 240×400 |
| Sammensætning | LCM |
| Lysstyrke | 130 |
| CR | 100:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | |
| panel mærke | TIANMA |
| panel model | TM030LDHT2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 240(RGB)×400 , WQVGA |
| visningstilstand | ECB, Normally White, Transflective |
| aktivt område | 38.88×64.8 mm |
| omrids | 47.28×76.4 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 130 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| vise farver | 65K/262K |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 40/45/55/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| Ansøgning | HHP |
