| Varenummer | ET043001DM6 |
| Mærke | EDT |
| Størrelse | 4.3 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 230 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | EDT |
| panel model | ET043001DM6 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2×4.25 mm |
| overflade | |
| lysstyrke | 230 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/45/75 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 7S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| indgangsspænding | 2.5/5.0V (Typ.)(VCC/AVDD) |
| Ansøgning | PND |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| DLC0430LZG-8 | Other | 4.3 | 480×272 |
| ET043001DM6 | EDT | 4.3 | 480×272 |
| G043FW01 V0 | AUO | 4.3 | 480×272 |
| HSD043I9W1-A01 | HannStar | 4.3 | 480×272 |
| LB043WQ2-TD08 | LG Display | 4.3 | 480×272 |
| LMS430HF12-003 | Samsung | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| NL4827HC19-05A | NLT | 4.3 | 480×272 |
| TD043MGEB1 | TPO | 4.3 | 800×480 |
| 43WQW3H | SII | 4.3 | 480×272 |
| A040FL01 V2 | AUO | 4.0 | 480×272 |
| ET043001DM6 | EDT | 4.3 | 480×272 |
| LB043WQ2-TD08 | LG Display | 4.3 | 480×272 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LMS430HF18 | Samsung | 4.3 | 480×272 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| P0430WQLC-T | CMEL | 4.3 | 480×272 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
