| Varenummer | TM035NDH04 |
| Mærke | Tianma |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 272×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | TIANMA |
| panel model | TM035NDH04 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 272(RGB)×480 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 43.86×77.4 mm |
| omrids | 50.86×87.98×2.5 mm |
| overflade | Antiglare |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 65K/262K , CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 60/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S6PWLEDWithout Driver |
| signal interface | CPU, 41 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | HHP |
