| Varenummer | P070ACB-DB1 |
| Mærke | Innolux |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 600×1024 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | CHIMEI INNOLUX |
| panel model | P070ACB-DB1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 600(RGB)×1024 , WSVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 89.28×152.37 mm |
| omrids | 95×163.27×4.15 mm |
| overflade | Hard coating (7H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S3PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
