| Varenummer | LSL080AL02-002 |
| Mærke | Samsung |
| Størrelse | 8.0 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | MIPI |
| panel mærke | SAMSUNG |
| panel model | LSL080AL02-002 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 107.64×172.224 mm |
| omrids | 112.64×181.824×0.69 mm |
| overflade | Glare (Haze 0%), Hard coating |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 6.6% (Typ.)(with Polarizer) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| Ansøgning | PAD |
