| Varenummer | PD035VX8 |
| Mærke | E Ink |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 480×640 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | PVI |
| panel model | PD035VX8 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×640 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 53.28×71.04 mm |
| omrids | 64×85×4.5 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S3PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 61 pins |
| Ansøgning | HHP |
