| Varenummer | TD020THEG1 |
| Mærke | TPO |
| Størrelse | 2.0 |
| Ansøgning | DSC |
| Løsning | 640×240 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TPO |
| panel model | TD020THEG1 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 2.0 inch |
| løsning | 640×240 , HVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 40.672×30.48 mm |
| omrids | 46.1×40.96 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (6-bit + Dithering) |
| responstid | 13/22 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsWLEDWithout Driver |
| signal interface | Analog RGB + LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.0V (Typ.) |
| Ansøgning | DSC |
| AM-320240-020A | Other | 2.0 | 320×240 |
| DLC0200EUG | Other | 2.0 | 240×320 |
| EG020AS012 | PDI | 2.0 | 200×96 |
| LQ020B3DC01 | SHARP | 2.0 | 176×220 |
| LS020B8UD02 | SHARP | 2.0 | 176×220 |
| OEL9M0064-G-E | Other | 2.0 | 128×32 |
| OEL9M0064-R-E | Other | 2.0 | 128×32 |
| OEL9M0064-W-E | Other | 2.0 | 128×32 |
| TD020THEG1 | TPO | 2.0 | 640×240 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
| A025DL02 V5 | AUO | 2.5 | 320×240 |
| A027DN03 V3 | AUO | 2.7 | 320×240 |
| A027DTN01.2 | AUO | 2.7 | 320×240 |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| CLAA030HA22DE | CPT | 3.0 | 960×480(dot) |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| LTV350QV-F0E | Samsung | 3.5 | 320×240 |
