| Varenummer | HSD040I3N1-B00 |
| Mærke | HannStar |
| Størrelse | 4.0 |
| Ansøgning | CNS |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 4700 |
| CR | 350:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | HannStar |
| panel model | HSD040I3N1-B00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 82.08×61.56 mm |
| omrids | 112.11×80.51×8.3 mm |
| overflade | |
| lysstyrke | 4700 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193145% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
