| Varenummer | A035VL01 V6 |
| Mærke | AUO |
| Størrelse | 3.5 |
| Ansøgning | DSC |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 315 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A035VL01 V6 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 75.6×45.36 mm |
| omrids | 86.1×51.66 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 315 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/30 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 70 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Ansøgning | DSC |
| 35HVE0H | SII | 3.5 | 320×480 |
| A035VL01 V0 | AUO | 3.5 | 800×480 |
| A035VL01 V3 | AUO | 3.5 | 800×480 |
| A035VL01 V6 | AUO | 3.5 | 800×480 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| PW035XU1 | E Ink | 3.5 | 320×234 |
| TD035STEB1 | TPO | 3.5 | 240×320 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035PDH53 | Tianma | 3.5 | 320×480 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A025DN01 V3 | AUO | 2.5 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| PA025XSC | E Ink | 2.5 | 480×234 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| TM027CDH04 | Tianma | 2.7 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
