| Varenummer | A050FW03 V0 |
| Mærke | AUO |
| Størrelse | 5.0 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A050FW03 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 110.88×62.832 mm |
| omrids | 120.7×75.8×4.45 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 7/23 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 67 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | PND |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| DLC0500AIG-2 | Other | 5.0 | 640×480 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LQ5AW136R | SHARP | 5.0 | 320×234 |
| PD050VX2 | E Ink | 5.0 | 480×640 |
| TM050QDH01 | Tianma | 5.0 | 640×480 |
| 35HVE0H | SII | 3.5 | 320×480 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LMS430HF02 | Samsung | 4.3 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS480KC02 | Samsung | 4.8 | 800×480 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| P0430WQLC-T | CMEL | 4.3 | 480×272 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
