| Varenummer | AM-240320GTZQW-02H |
| Mærke | AMPIRE |
| Størrelse | 2.8 |
| Ansøgning | Mobile Phone |
| Løsning | 240×320 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 450:1 |
| Farver | 65K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| mærke | AMPIRE |
| model | AM-240320GTZQW-02H |
| diagonal størrelse | 2.8 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 240(RGB)×320 [QVGA] 141PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 43.2(H)×57.6(V) mm |
| omrids dim. | 49(H)×67.5(V) ×4.9(D) mm |
| luminans | 280 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | MVA, Normally Black, Transmissive |
| støtte farve | 65K 69% NTSC |
| lyskilde | WLED [3S2P] , With LED Driver |
| vægt | TBD |
| designet til | Mobile Phone |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | CPU/RGB/SPI , 40 pins FPC |
| Strømforsyning | 2.8V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-240320-022F | Other | 2.2 | 240×320 |
| AM-240320-024DT | Other | 2.4 | 240×320 |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| F-55472GNFJ-SLW-AAN | Kyocera | 2.8 | 128×64 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LTV280QV-F02 | Samsung | 2.8 | 320×240 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| TFT240320-237-E | Other | 2.8 | 240×320 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
