| Varenummer | DLC0320DUG |
| Mærke | Other |
| Størrelse | 3.2 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 110 |
| CR | 30:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | DLC |
| panel model | DLC0320DUG 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.2 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 48.6×64.8 mm |
| omrids | 57.54×79.2 mm |
| overflade | |
| lysstyrke | 110 cd/m² (Typ.) |
| kontrastforhold | 30:1 (Typ.)(Transmissive)2.5:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193142% |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 40/25/65/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S1PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 40 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(VCI/VDD3) |
| Ansøgning | MPH |
| DLC0300AMG | Other | 3.0 | 240×400 |
| DLC0320DUG | Other | 3.2 | 240×320 |
| DLC0350AMG-4 | Other | 3.5 | 320×240 |
| DLC0350BMG-1 | Other | 3.5 | 240×320 |
| DLC0350CZG-T | Other | 3.5 | 320×240 |
| DLC0350CZG-T-2 | Other | 3.5 | 320×240 |
| DLC0350FVG-5 | Other | 3.5 | 320×240 |
| DLC0350SZG | Other | 3.5 | 480×640 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| RGS32256064YH001 | RiTdisplay | 3.2 | 256×64 |
| AMS529BY01 | Samsung | 5.3 | 1080×1920 |
| CLAF050LG41 TXX | CPT | 5.0 | 540×960 |
| CLAN050LE61 1XE | CPT | 5.0 | 540×960 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LH500WF1-SD02 | LG Display | 5.0 | 1080×1920 |
| LH500WF3-SH01 | LG Display | 5.0 | 1080×1920 |
| LS035Y8DX04A | SHARP | 3.5 | 480×800 |
| LS038Y7DX01 | SHARP | 3.8 | 480×800 |
| TM022GBH01 | Tianma | 2.2 | 176×220 |
