| Varenummer | LQ040Y3DX80 |
| Mærke | SHARP |
| Størrelse | 4.0 |
| Ansøgning | HHP |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ040Y3DX80 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 51.84×86.4 mm |
| omrids | 57.14×96.85×2 mm |
| overflade | |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| indgangsspænding | 2.8/1.8V (Typ.)(VCI/IOVCC) |
| Ansøgning | HHP |
