| Varenummer | LH500WF1-SD02 |
| Mærke | LG Display |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LH500WF1-SD02 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 62.37×110.88 mm |
| omrids | 65.27×117.88×1.55 mm |
| overflade | Clear |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 30 pins |
| indgangsspænding | 1.8/5.0/-5.0V (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | MPH |
