| Varenummer | LS040T3SW01 |
| Mærke | SHARP |
| Størrelse | 4.0 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | LCM |
| Lysstyrke | 515 |
| CR | 450:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS040T3SW01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 49.41×87.84 mm |
| overflade | Antiglare (Haze 45%) |
| lysstyrke | 515 cd/m² (Typ.) |
| kontrastforhold | 450:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 12/24 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 40 pins |
| indgangsspænding | 1.85/2.85V (Typ.)(vcci/avci) |
| Ansøgning | MPH |
