| Varenummer | S035V01 |
| Mærke | CDTECH |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 480×640 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | CDTECH |
| panel model | S035V01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×640 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 53.28×71.04 mm |
| omrids | 64×85 mm |
| overflade | |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S2PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 61 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| Ansøgning | HHP |
