| Varenummer | 28QVF2J |
| Mærke | SII |
| Størrelse | 2.8 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 28QVF2J |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 43.2×57.6 mm |
| omrids | 49×69 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 4S1PWLED |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 35 pins |
| indgangsspænding | (1.65~3.3)/(2.5~3.3)(IOVCC/VCI) |
| Ansøgning | HHP |
| 28QVF1H | SII | 2.8 | 240×320 |
| 28QVF1J | SII | 2.8 | 240×320 |
| 28QVF2H | SII | 2.8 | 240×320 |
| 28QVF2J | SII | 2.8 | 240×320 |
| BTL282440-310L | BOE | 2.8 | 240×400 |
| ET028002DMU | EDT | 2.8 | 240×320 |
| F-55472GNFJ-SLW-AAN | Kyocera | 2.8 | 128×64 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LTP280QV-E01 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| 24QVF2H | SII | 2.4 | 240×320 |
| AM-240320-022F | Other | 2.2 | 240×320 |
| AM-320240-015A | Other | 1.5 | 320×240 |
| AM-320480-035BT | Other | 3.5 | 320×480 |
| COM24H2N62XLC | ORTUSTECH | 2.4 | 240×320 |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| LQ039Q2DS51 | SHARP | 3.9 | 320×240 |
| LQ040Y3DX80B | SHARP | 4.0 | 480×800 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| YX035CM31 | 3.5 | 320×240 |
