| Varenummer | DLC0350SZG |
| Mærke | Other |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 480×640 |
| Sammensætning | LCM |
| Lysstyrke | 120 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | DLC |
| panel model | DLC0350SZG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×640 , VGA |
| visningstilstand | Normally Black, Transflective |
| aktivt område | 53.57×71.42 mm |
| omrids | 64×85×5.2 mm |
| overflade | |
| lysstyrke | 120 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193155% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
