| Varenummer | 32WVF0H |
| Mærke | SII |
| Størrelse | 3.2 |
| Ansøgning | HHP |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 32WVF0H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.2 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 41.76×69.6 mm |
| omrids | 47.3×80 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + Dithering), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLED |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| Ansøgning | HHP |
| 32WQF0H | SII | 3.2 | 240×400 |
| 32WVF0H | SII | 3.2 | 480×800 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| HVA32WV1-D00 | HYDIS | 3.2 | 480×800 |
| LS032B7LX02 | SHARP | 3.2 | 320×480 |
| LT032MDQ7000 | JDI | 3.2 | 360×480 |
| RGS32256064YH001 | RiTdisplay | 3.2 | 256×64 |
| TFT2N0369-E | Other | 3.2 | 240×320 |
| TM032PDZ13 | Tianma | 3.2 | 320×480 |
| 24QVW1H | SII | 2.4 | 240×320 |
| 32NHF0H | SII | 3.2 | 360×640 |
| CMD500TT10-C1 | ORTUSTECH | 3.2 | 320×240 |
| COM24H2N62XLC | ORTUSTECH | 2.4 | 240×320 |
| COM41H4M31XLC | ORTUSTECH | 4.1 | 320×240 |
| LQ038Q7DB03 | SHARP | 3.8 | 240×320 |
| LS037V7DW03A | SHARP | 3.7 | 480×640 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| S035V01 | CDTECH | 3.5 | 480×640 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
